Single view x-ray baggage scanner with high steel penetration and wire resolution

Name: Single view xray baggage scanner with high steel penetration and wire resolution
Brand: Uniqscan
Price: 1 USD

Brand Name : Uniqscan

Model Number : SF5636

Certification : CE;ISO

Place of Origin : Shenzhen

MOQ : 1 unit

Price : negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100 sets per month

Delivery Time : in one week

Packaging Details : wooden box

application : public security

certification : CE:ISO

model : SF5636

Conveyor speed : 0.22m/s

tunnel size : 500(w)x300(h)mm

wire resolution : 40AWG

warranty : 2 years

Contact Now

Single view x-ray baggage scanner with high steel penetration and wire resolution

X-RAY generator
Orientation: Upward
Tube Current:0.4~0.7mA(adjustable)
Anode Voltage:80KV(adjustable)
Angle: 60°
Generator cooling/working periods:
Sealed oil bath with forced air/100%

Film Safety: For ISO 1600

Airport Baggage X Ray Machine Sf5636 Dual Energy Scanner Ce / Iso Certificated

Application:
Exhibition center, Electronic Factory, Bank, Prison, Government office,Hotel etc

Parameter
General specification	X-ray Generator
Tunnel Size : 500(W)×300(H)mm	Orientation: Upward;
Conveyor Speed: 0.22m/s	Tube Current: 0.4~0.7MA(adjustable)
Conveyor Max Load: 100 kg	Anode voltage: 80KV(adjustable)
Single inspection dosage:< 1.32μGy	X-ray divergence angle: 60 °
Leakage radiation dosage:≤ 0.14µGy/h	Generator cooling/working periods:
Wire resolution: 40AWG	sealed oil bath with forced air/100%
Spatial resolution :1.0mm Horizontal ;1.0mm Vertical	X-RAY Sensor:
Steel Penetration: 10mm steel plate	L-shaped array detector, 24bit
Film safety: for ISO1600

Features

Single-Energy ,L-shaped array detector

apan HAMMATSU detector crystal , Detecting board from Deetee Finland.

IPC from Taiwan , Interroll Roller from German

High-resolution PHILIP 19 inch color LCD display

Four colors to distinguish organic , inorganic and dangerous material

Multiple functions: High/Low penetration display, Magnifier, Brightening/dimming,

Image enlarge, recurrence, restoration, storage, network

Our service
2 years warranty for free parts.
Free training in the factoty and on the video.
We have professional global team to solve your pronlem
We provide the HD images and video also can do in your brand(OEM)
We can fly to you local to help you finish installing and so on business.

The image of SF5636
