AC 85V-264V 33 Zones Airport Door Frame Metal Detector

Name: AC 85V264V 33 Zones Airport Door Frame Metal Detector
Brand: Uniqscan
Price: 1 USD

Brand Name : Uniqscan

Model Number : UB800

Certification : CE ISO

Place of Origin : China

MOQ : 1 UNIT

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 20000pcs per month

Delivery Time : 5-8 work days

Packaging Details : carton box

Product Name : Walk Through Body Scanner Gate

Warranty : 2 years

Power supply : AC85V-264V

Sensitivity : 999 Sensitivity Level

Material : High density wood

Display : 7 inch color LCD screen

Detection zone : 33 zones

Key Feature : Infrared remote control

Usage : hotel,school,public area

Gross Weight : 65KG

Contact Now

UNIQSCAN 33 Detecting Zones Door Frame Metal Detector Walk Through Body Security Scanner Gate For Airport Checking

Parameters :

Detecting zone:	33/36 zone
Display way:	7 inch color LCD screen
Sensitivity:	0-999 adjustable
Detecting speed:	up to 100 passenger/ min.
Working temperature:	-20ºC--+50ºC
PASS and ALARM count:	up to 99999
Gross weight:	67KG
Warranty:	2 years
Standard External size:	2200mm(H)X800mm(W)X580mm(D)
Standard Internal size:	2010mm(H)X700mm(W)X500mm(D)
Package size for door panels:	2260650260mm *1ctn
Package size for control unit:	780390250 mm*1ctn

CHARACTERISTIC & FUNCTION:

33 detecting zones, Simultaneous alarm from multi- zones;
Sensitivity adjustable: Each zone has 999 sensitivity level 0-999 adjustable
7 inch color LCD screen
Infrared remote control
Using high density fireproof material
Automatically count passengers and alarm times
PASS and ALARM count: up to 99999
High sensitivity: Ferrous/ non-ferrous /Alloy can be detected
15 preset programs for security applications
Alarm volume range from level 0 to 9
Alarm tones: Change from 1 to 9
100 frequencies for option. To work with neighbouring gates at 50cm
Sound & LED alarm: Two Sides LED indicator easily show where the metal is.
Detecting speed: up to 100 passenger/ min.
Password protection, only the authorized person can operate.
Easy assembly: designed with only 2 pieces cables and 8 screws,
Modularization design,easy for maintenance and replacement.
Sensitivity Test piece: One yuan Coin, omnidirectional detection
Network support
Can be customized 36 zones
4-8 hours backup battery (Option)

Specification of Camera and DVR :

Camera: 2 adjustable infrared cameras , one for entry , one for exit
Video Input : 2 channel
Video output : 1 channel
USB slot
SD card slot
Screen: 7" LCD colored with IR remote control
Resolution : 1280*720
Audio input : 2 channel Audio output: 1 channel
Working mode : video and recording mode-auto/manual
Mermory : support 128G removable sd card Power consumption : 5-30V
Language : English/Chinese
DVR Size : 2.6''x 3.5'' in die cast aluminium body
Remote controller IR for control of complete menu on screen display

Detail Photo :

AC 85V-264V 33 Zones Airport Door Frame Metal Detector

Shipment:

Payment terms	T/T, Western Union, Cash,L/C
Shipping methods	By air (5-7days, most expensive)
	By express (3-7days, more expensive)
	By sea (15-28days, cheapest)
